Methane Measuring, Monitoring, Modeling and Methods

July 20, 2022

SCS Engineers Environmental Consulting and Contracting
As technologies and policies evolve, so have the ways SCS Engineers take measurements depending on each landfill’s unique characteristics and infrastructure.



Many landfills are still using hand-held monitoring of methane “hot spots” for compliance purposes while relying on models to estimate LFG emissions. Although technological developments in optical remote sensing and other methods offer significant improvements to measuring actual surface emissions from landfills, no single technology or method has risen to the top of the scientific hierarchy, gained universal acceptance, and achieved regulatory approval. Clearly, the technological advances provide more comprehensive methods for measuring methane concentration, identifying methane hot spots and leaks, and providing better coverage of the entire landfill surface. However, some technology falls short in their ability to provide accurate, consistent, and repeatable methane flux or emissions measurements.

As monitoring technology evolves, so have the various ways SCS takes measurements, from source level, drones, and high-altitude aircraft, to satellites. This paper presented at A&WMA by Patrick Sullivan and Raymond Huff summarises and provides details on the following methods:

• First order decay (FOD) modeling for landfills without active LFG collection systems.
• Non-FOD modeling for landfills without active LFG collection systems.
• FOD modeling with measured LFG collection.
• Non-FOD models with various site-specific data input.
• Measured LFG collection with estimated collection efficiency.
• Surface emission monitoring for compliance purposes.
• Ground-based or low-altitude imaging for concentration or hot spot measurement.
• Satellite and aerial imaging for concentration or hot spot measurement.
• Flux chamber testing.
• Ground-level plume measurement.
• Micrometeorology.
• Stationary path measurement.
• Reverse air dispersion modeling.
• Tracer studies.
• Low or high-altitude imaging.
• Hybrid methods.



Click to read The Evolution of Methane Emissions Measurements at Landfills: Where are We Now?



Posted by Diane Samuels at 6:02 am

Intercontinental Landfill Research Symposium Call for Sessions Open through February 25

February 25, 2022

The 11th Intercontinental Landfill Research Symposium (ICLRS 2022) will take place on the East Coast of the United States in September 2022.  The exact date and location will be announced shortly.

The ICLRS is the premier international meeting for exchange of ideas among landfill researchers throughout the world.  The Call for Sessions is currently open through February 25, 2022.  Session proposers should provide a paragraph on the topic background and list session objectives, subjects to be addressed, and potential presenters. Abstracts will be due in the Summer.

In contrast to other meetings, the focus of this meeting is on leading edge research covering all aspects of landfills. The objectives of the symposium are to (1) assemble world’s leading researchers and practitioners in the solid waste field, (2) address a broad range of topics related to landfills, and (3) discuss and debate current knowledge and future directions. The emphasis of the ICLRS is on critical discussion and detailed exploration of a topic. To this end, sessions are typically 2-3 hours and include 4 to 5 presentations. Each session is designed so that at least 50% of the time is spent on discussion. Past ICLRS Sessions included:

  • Landfill mining
  • Landfill covers – materials and design
  • Landfill aeration
  • Even gas distribution in methane oxidation systems
  • Anaerobic decomposition of forest products in landfills
  • Methane oxidation systems
  • Modeling landfill gas
  • The use of stable isotopes for quantification of methane oxidation in landfill
  • Disaster waste
  • The fate of emerging compounds in landfills
  • Landfill post-closure care
  • Landfill stabilization and sustainable landfill

Organizers: Environmental Research & Education Foundation (EREF), Tarek Abichou (Florida State University), Morton Barlaz (North Carolina State University), Nicole Berge (University of South Carolina), Anders Lagerkvist, (Luleå University of Technology) and Debra Reinhart (University of Central Florida)

The conference is taking shape.  Click here for updates, details, and information on submitting Session Proposals.







Posted by Laura Dorn at 8:00 am

NWRA and SWANA Provide Comments on the EPA’s Proposed Revisions to the Prevention of Significant Deterioration (PSD)

January 9, 2017

On behalf of the solid waste industry, the NWRA and SWANA  both not-for-profit associations provided comments on the EPA’s proposed Revisions to the Prevention of Significant Deterioration (PSD) and Title V Greenhouse Gas (GHG) Permitting Regulations and Establishment of a Significant Emissions Rate (SER) for GHG Emissions Under the PSD Program (81 FR 68110), which we’ll call the PSD Revisions. The comments were submitted on December 16, 2016.



EPA is proposing a GHG SER of 75,000 tons per year (tpy) Carbon Dioxide equivalent (CO2e) and requesting comment on it as well as two lower levels, specifically 30,000 tpy and 45,000 tpy CO2e, respectively.

The Associations do not believe there is sufficient information to support lowering the GHG SER below the proposed 75,000 tpy CO2e level and provided a table utilizing equivalent criteria pollutants from combustion sources (i.e., NOx, CO) yields CO2 emissions as high as 780,000 tpy CO2.

EPA already concluded in USEPA, Proposed PSD Revisions Rule, 81 FR 68137 that the burdens of regulation at a GHG SER level between 30,000 and 75,000 tpy CO2e would yield a gain of trivial or no value from both a programmatic and individual project-level perspective. Therefore, NWRA and SWANA strongly recommend EPA retain proposed GHG SER of 75,000 CO2e (or higher), and resist pressure to lower the GHG SER.






On the Topic of Biogenic GHG Emissions, the EPA’s final rule requires clarification to remain consistent with previous documentation and research to prevent significant permitting delays and increased costs that will not result in meaningful emission reductions.

The Associations encourage the EPA to ensure that waste-derived biogenic CO2 (e.g., from municipal solid waste (MSW) landfills) is treated as carbon neutral under the final PSD Permitting Revisions Rule to be consistent with prior Agency determinations specified in this memorandum and documents as follows:S. EPA, Memorandum Addressing Biogenic Carbon Dioxide Emissions from Stationary Sources, McCabe, Janet, November 19, 2014.

S. EPA, Memorandum Addressing Biogenic Carbon Dioxide Emissions from Stationary Sources, McCabe, Janet, November 19, 2014. The documents highlight waste-derived, biogenic CO2 as a type of “carbon neutral” feedstock based on the conclusions supported by a variety of technical studies and conclusions of the Agency’s latest draft Framework for Assessing Biogenic Carbon Dioxide for Stationary Sources, which was released with the memo. The Agency memo stated that “the Agency expects to recognize the biogenic CO2 emissions and climate policy benefits of such feedstocks in [the] implementation of the CPP.”

US EPA, Emission Guidelines for EGUs, 80 FR 64855. Both the revised Framework, and the EPA’s Scientific Advisory Board (SAB) peer review of the 2011 Draft Framework, found “that the use of biomass feedstocks derived from the decomposition of biogenic waste in landfills, compost facilities, or anaerobic digesters did not constitute a net contribution of biogenic CO2 emissions to the atmosphere.”

S. EPA, Appendix N. of Revised Framework for Assessing biogenic Carbon Dioxide for Stationary Sources, November 2014, pg. N-25. In Appendix N. of the Framework, entitled Emissions from Waste-Derived Biogenic Feedstocks, EPA calculated negative Biogenic Accounting Factors (BAF) for various examples of treatment of landfill gas via collection and combustion. EPA explains, “Negative BAF values indicate that combustion of collected landfill gas feedstock by a stationary source results in a net CO2e emissions reduction relative to releasing collected gas without treatment.”

US EPA, Carbon Pollution Emission Guidelines for Existing Stationary Sources: Electric Generating Units; Final Rule [Emission Guidelines for EGUs], 80 FR 64885. “[T]he use of some biomass-derived fuels can play a role in controlling increases of [in] CO2 levels in the atmosph The use of some kinds of biomass has the potential to offer a wide range of environmental benefits, including carbon benefits.”

US EPA, Emission Guidelines for EGUs, 80 FR 94855. Types of waste-derived biogenic feedstocks may include: landfill gas generated through decomposition of MSW [municipal solid waste] in a landfill; biogas generated from the decomposition of livestock waste, biogenic MSW, and/or other food waste in an anaerobic digester; biogas generated through the treatment of waste water, due to the anaerobic decomposition of biological materials; livestock waste; and the biogenic fraction of MSW at waste-to-energy facilities.






NWRA and SWANA believe the final PSD Revisions document should follow the approach to waste-derived feedstocks enshrined in the Final Clean Power Plan, and as recommended by the SAB, and ensure that waste-derived biogenic CO2 is treated as carbon neutral. Based on EPA’s own lifecycle assessments for the Renewable Fuels Standard program, its U.S. GHG Inventory, and confirmed by the SAB, EPA has sufficient analysis to support exclusion of selected categories of biogenic emissions from PSD permitting, including those from managing landfill gas and organic components of MSW.

The EPA does not seem to consider the regulatory treatment of biogenic CO2 from stationary sources to be a key issue in the context of the PSD revisions rule, based on a comment found in a Summary of Interagency Working Comments on Draft Language.  Instead, the EPA continues to believe this rulemaking to establish a GHG SER under the PSD program is not the appropriate venue to address the broader concern of the regulatory treatment of biogenic CO2 from stationary sources.

The Associations strongly disagree and are concerned that because EPA remains silent on this important issue, some permitting authorities might improperly require landfills to incorporate biogenic CO2 emissions in the PSD permitting process.  Historically, few landfills triggered PSD because non-methane organics emissions rarely reached the threshold. However, if biogenic CO2 emissions become subject to PSD, many landfill projects, which are “anyway sources” due to renewable energy projects, would also be forced to do BACT analysis for GHG. Biogenic CO2 is emitted from:

  • Methane control devices that convert methane to CO2 and destroy NMOCs per the Landfill NSPS/EG Rules;
  • Engines and turbines that use landfill gas as fuel to produce renewable electricity;
  • Treatment of landfill gas to pipeline quality for use as renewable transportation or facility fuel; and
  • Methane that moves through landfill cover where bacteria converts it to CO2.

From the perspective of developing new renewable transportation fuel or energy projects, subjecting biogenic emissions from landfills to PSD could be an enormous barrier.  The Associations would like the EPA to clarify in its final rule that the emissions of biogenic CO2 from treating or controlling landfill gas does not increase the CO2 levels in the atmosphere, but instead, has positive emission reduction and climate benefits.  Failing to clarify this important point could subject landfills to significant permitting delays and increased costs that will result in no meaningful emission reductions.



Questions? Contact SWANA, NWRA, Patrick Sullivan, or your local SCS office.









Posted by Diane Samuels at 3:00 am

EPA Information Summaries: Limitations on Methane Emissions From Oil and Gas Wells

May 13, 2016

An SCS Engineers Technical Bulletin will be released early in the week.

The U.S. Environmental Protection Agency issued limits on methane emissions from oil and gas wells that are more stringent than those it proposed last year. The final regulations released on Thursday, May 12, 2016, will add hundreds of millions in additional costs per year; at least 25 percent higher than the preliminary version published in August 2015.

EPA Administrator Gina McCarthy told reporters on a conference call that the mandates, applying immediately to new and modified wells, are a “critical first step in tackling methane emissions from existing oil and gas sources.”

Under the rule, companies must upgrade pumps and compressors while expanding the use of “green completion” technology meant to capture the surge of gas that can spring out of newly fracked wells. Such green completion techniques have been required for new and modified natural gas wells since 2015, but Thursday’s rule would broaden the requirement to oil wells too.

Take me to the EPA summaries. Click on the information sheets listed below:

Posted by Diane Samuels at 6:13 pm

Leak Detection and Repair – LDAR Fugitive Emissions

March 7, 2016



Fugitive emissions come in all shapes and sizes, are found in several industry types, and the constituents entrained in them generally have potential negative impacts on our health and the environment.  That being said, no wonder they are called “fugitive” emissions.  It seems to be in our human nature to seek out, capture, and prevent any sort of fugitive activity.



LDAR and other environmental and compliance services are available from SCS Engineers.
LDAR and other environmental and compliance services are available from SCS Engineers.

Long story short, an escapee from San Quentin and any uncontrolled methane air molecule may be more similar than we may presume.  In fact, a common LDAR practice is to use an infrared imaging camera; similar to the camera often used in search of fugitive criminals.

On a serious note, fugitive emissions are something that both industry and regulators have been focused on for decades, and the past and present efforts made to limit them are no less than remarkable.

Specific to Onshore Oil and Gas Exploration & Production, the Federal Regulations applicable to fugitive emissions are fairly young.  Finalized in 2012, NSPS OOOO is no longer a toddler and is in the middle of growing into NSPS OOOOa (Public Comment Deadline March 11, 2016).  On a national scale, NSPS OOOOa will expand fugitive emission monitoring and control requirements (VOC’s and methane) to several facility types associated with the industry and is expected to be finalized before the close of 2016.

In California, fugitive emissions from Onshore Oil and Gas Exploration & Production have been regulated for a long time.  In fact, the O&G industry in Santa Barbara County has dealt with fugitive emission requirements since 1979.  Since then SCS Engineers has been assisting with fugitive emission monitoring for our valued clients.  Today, SCS Engineers provides the Oil and Gas Exploration and Production industry with efficient and effective LDAR services.

So fear not, SCS Engineers is ready to supply the knowledge and skill set you need to stay compliant, maintain your operations, and respect your bottom line.  Remember, unless the doors are closed, pumps are turned off, and equipment is flushed and plugged; fugitive emissions requirements and LDAR will likely still apply.

If you are considering a new LDAR program, restoring an existing program, or are still trying to figure out what LDAR actually is, below are a few basic pieces of advice:

Applicability:  Determining Federal vs. State oversight is the first step.  Non-Major Source Oil and Gas Production facilities are either subject to NSPS OOOO (soon to be OOOOa) or a related State specific rule (i.e. Colorado Regulation 7).  Once oversight is determined, then there may still be exemptions for your facility (i.e. facility constructed before August 23, 2011).  And finally, once regulatory oversight is confirmed and you determine that LDAR is required for your facility, then the last step is to figure out which equipment is applicable (i.e. VOC content > 10% by weight).  Basically, an applicability determination can be daunting.

Equipment: EPA’s Method 21 is historically and currently referenced in all LDAR regulations.  Method 21 requires an instrument such as the Flame Ionization Detector (FID) or Photo Ionization Detector (PID).  More recently the Optical Gas Imaging (OGI) Camera has been included in LDAR regulations and utilized in LDAR programs.  Presently, there are several instrument technologies that exist and are in the works, but not yet mainstream in Oil and Gas sector.  Ultimately, if you were to find yourself conducting LDAR monitoring at your oil and gas facility tomorrow per an established regulation, you would most likely need to use an FID or OGI.

Recordkeeping:   Personally, I like the simplicity of using paper forms for field notes; however, the old-fashioned way comes with risk. The up-front and ongoing data involved with an LDAR program is too much for maintaining a paper to computer process, regardless of how organized you think you are. Therefore, a computer database platform is recommended and necessary for managing your LDAR recordkeeping. Beyond just recordkeeping, a database platform can organize schedules, alerts, generate reports, extract trends, and many other applications to help keep your LDAR program compliant.  One such platform worth considering is SCSeTools™.  This cloud-based software can provide the database capabilities used on the desktop, but almost more importantly, provides mobile data input capabilities with the SCS MobileTools™ application fit for Android and IOS systems. Keep the fugitives from escaping, and document containment for the authorities!

If you are not already implementing an LDAR program at your Oil and Gas Production Facility, it may be on the near horizon; especially after Leo’s recent Academy Award speech.



Marsalek_LucasAbout Lucas Marsalek: Lucas has been an Environmental Consultant for over 8 years; he applies his expertise as a leader for oil and gas production environmental and regulatory compliance projects. Marsalek has a B.S. in Forestry and Natural Resource Management from California Polytechnic State University, San Luis Obispo, CA.

Whether you want to discuss LDAR or Dodger baseball, don’t hesitate to contact me, or SCS Engineers.



Resources:

Learn more on the SCS service pages and read SCS project case studies from across the nation to help fine tune your program.





Outside links to the EPA proposed rulemaking website:



Posted by Diane Samuels at 6:00 am

What do Climate Change, AB 32, and Ray Huff have in common?

October 22, 2015

GHG_AB32-scs-engineersThe Global Warming Solutions Act of 2006, or Assembly Bill (AB) 32, is a California State Law that fights climate change by establishing a comprehensive program to reduce greenhouse gas emissions GHG from all sources throughout the state.  AB 32 is the first state regulatory program in the country to take a comprehensive, long-term approach to addressing climate change. A major component of the program, the Landfill Methane Rule, requires landfill owner/operators to reduce methane emissions through proper operation of landfill gas LFG collection and control systems and collect and report  GHG emissions data in a timely manner. GHG emissions are defined in the AB 32 to include all of the following: carbon dioxide, methane, nitrous oxide, sulfur hexafluoride, hydrofluorocarbons, and perfluorocarbons.

SCS is a pioneer in our nation’s efforts to reduce GHG emissions in order to combat global warming. We proactively pursue the development of markets in which major sources of methane (e.g., oil and gas industry, landfills, dairies, etc.) can generate and sell GHG credits by voluntarily installing methane recovery systems and selling the methane as fuel.

Methane is 25 times more powerful than carbon dioxide in terms of its greenhouse effect. Capturing and destroying these emissions can have significant environmental benefits. Simply destroying methane via power generation or sequestration can diminish its GHG potential by 95 percent. Even greater benefits are available if the methane is used as renewable energy in order to offset natural gas or coal-fired power generation.

To learn more contact our Ray Huff, our SCS National Expert on Greenhouse Gas Monitoring, Control, and Emissions.

Posted by Diane Samuels at 12:16 pm
